Facts & Figures
Cat.No.: 2205
31,514
Max. RCF
18,000 min-1
Max. RPM
330 x 650 x 313 mm
Dimensions (WxDxH)
60 x 1.5 / 2 ml | 6 x 50 ml
Max. capacity
-20 °C to +40 °C
Temperature Control
approx. 42 kg
Weight
Fast and flexible
The MIKRO 220 R spins at an unmatched speed of 18,000 RPM and delivers an RCF of 31,514 in just 26 seconds. It offers flexibility with a choice of 8 different rotors, accommodating tube sizes from 0.2 ml microliters to 50 ml conical tubes, enabling numerous research applications on a single machine. The MIKRO 220 R is equipped with refrigeration and offers a temperature range from -20 °C to +40 °C.
Areas of applications
Clinical
Spin pediatric tubes in a small compact footprint as well as PCR mini kits including spin columns up to 31,514 RCF and lipemic samples with a g-force of 21,185 at a fraction of the cost of an ultracentrifuge.
Industry and research
Spin PCR Mini Kits including spin columns and microliter tubes to sediment subcellular particles or bacteria.
Facilities
- Hospitals
- Paediatric hospitals
- Blood centers
- Pharmaceutical hospitals
- Food analyzing labs
- Scientifc Ll in universities
- Forensic labs
- Paternity testing labs
The right accessories for this centrifuge
Max. RCF: 18,516
Max. RPM: 13,000 min-1
Max. capacity: 24 x 2 ml
Angle: 90°
Standard equipment: Incl. Bio-containment lid
Cat.No.: 1154-L
Max. RCF: 31,514
Max. RPM: 18,000 min-1
Max. capacity: 24 x 2 ml
Angle: 45°
Standard equipment: Incl. Bio-containment lid
Cat.No.: 1195-A
Max. RCF: 21,255
Max. RPM: 14,000 min-1
Max. capacity: 30 x 2 ml
Angle: 45°
Standard equipment: Incl. Bio-containment lid
Cat.No.: 1189-A
Max. RCF: 21,255 + 18,845 (inner row)
Max. RPM: 14,000 min-1
Max. capacity: 48 x 2 ml
Angle: 45°
Standard equipment: Incl. Bio-containment lid
Cat.No.: 1158-L
Max. RCF: 4,025
Max. RPM: 6,000 min-1
Max. capacity: 6 x 50 ml
Angle: 35°
Cat.No.: 1016
Max. RCF: 14,171
Max. RPM: 13,000 min-1
Max. capacity: 60 x 2 ml
Angle: 90°
Cat.No.: 1161
Max. RCF: 4,146
Max. RPM: 6,000 min-1
Max. capacity: 12 x 15 ml
Angle: 35°
Cat.No.: 1015
Max. RCF: 18,845
Max. RPM: 14,000 min-1
Max. capacity: 6 x 8 PCR-Strips
Angle: 45°
Cat.No.: 1160
Packages
You get everything you need for your application in one package. Save time and stop searching for the right combination of accessories.
Show product packages![[Translate to French:] MIKRO 220 R Package 1](/fileadmin/_processed_/a/7/csm_MIKRO-220-R-Paket-1_575x575px_70c399e500.jpg)
![[Translate to French:] MIKRO 220 R Package](/fileadmin/_processed_/9/d/csm_MIKRO-220-R-Paket-2_575x575px_e94faf1ec6.jpg)
Downloads
- 1 MB
- EN
Cleaning & Care of Centrifuges
- 3 MB
- EN
- 66 MB
- EN
Data sheet | MIKRO 220 | 220 R
- 3 MB
- EN
- 4 MB
- EN, DE, FR, Others
- 116 KB
- FR, EN
