SBS 300 R Robotic

Powerful solution for optimal cooling

Choose product:

Facts & Figures

Cat.No.: 8305

4,615

Max. RCF

6,300 min-1

Max. RPM

412 x 508 x 313 mm

Dimensions (WxDxH)

approx. 80 kg

Weight

2 microtiter plates

Capacity

Powerful solution for optimal cooling

The SBS 300 R Robotic is a front-loading centrifuge, developed and optimized for microplates in high-throughput screening. It can be loaded frontally via the xy-axes, as well as via the z-axis and is particularly suitable for collaborative robotic systems.

The compact design opens up a wide range of applications in automation. The robust construction, ensures increased safety and durability – especially in high throughput and continual use environments.

For external cooling of the SBS 300 R Robotic, we recommend the MAGIO MX-2500F chiller from JULABO, a high-quality German manufacturer. This unit ensures top cooling performance and precise temperature control.

Advantages

Integration made easy

The robust construction, ensures increased safety and durability - especially in high throughput and continual use environments.

Front-loading - with Scara robots or Cobots

Top loading - with Linear robots

Top-loading - with Cobots

next
prev

Areas of applications

Life Science

Typical areas of application for the automated centrifuge are high-throughput screening (HTS) in pharmaceutical and crop protection research, food and cell analysis or the screening of bioreactions.

For sensitive samples, the SBS 300 R Robotic offers an external, separate cooling unit. The modular design ensures maximum integration flexibility.

Industry

The SBS 300 R Robotic is ideal for use wherever samples are prepared for subsequent analysis in microtitre plate format. The high centrifugal force allows organic and inorganic molecules to be separated.

Facilities

  • High-throughput laboratories
  • Pharmaceutical laboratories
  • Genetic engineering laboratories
  • Food analytics

The right accessories for this centrifuge

Swing-out rotor, 2-place

Max. RCF: 4,615

Max. RPM: 6,300 min-1

Angle: 90°

Capacity: 2 microtiter plates

Standard equipment: Buckets 8330-R/2 needed

Cat.No.: 8322-R

Bucket Set
  • Light-metal
  • Set consisting of 2 pieces
  • For rotor 8322-R

Cat.No.: 8330-R/2

External cooling unit MAGIO MX-2500F

For optimal external cooling of the SBS 300 R Robotic, we recommend the MAGIO MX-2500F chiller from JULABO, a renowned German manufacturer. This high-quality unit delivers excellent cooling performance and precise temperature control.

Please note:
The chiller can only be ordered directly from JULABO. Additionally, a compatible coolant and an interface cable are required.



Cat.No.: 9033752.N1

Packages

You get everything you need for your application in one package. Save time and stop searching for the right combination of accessories.

Show product packages
SBS 300 R Robotic - Set 1

1x | 8305 | RS232 Centrifuge
1x | 8322-R | Rotor
1x | 8330-R/2 | Bucket (Set of 2)
1x | RS232 Interface cable

next
prev
